SJK-7U 8MHz SMD3225 Quartz Crystal Unit High Precision And Stability Appication For Indusrtial Control

Brand Name : SJK

Model Number : SJK 7U SMD3225 8MHz Quartz Crystal

Certification : SGS, RoHS, REACH

Place of Origin : China

MOQ : 3000pcs

Price : Negotiate

Payment Terms : T/T

Supply Ability : 30K pcs per Month

Delivery Time : 2~4weeks

Packaging Details : 3000pcs /Reel

Type : SJK-7U SMD3225 Quartz Crystal

Overtone Order : Fundamental

Nomainal Frequency : 8MHz

Frequency Tolerance : +/-10ppm

Load Capacitance : 12pF

Drive Level : 100uW

Equivalent Series Resistance : 150Ω max

Operating Temperature : -40°C to +85°C

Storage Temperature Range : -55°C to +125°C

Size : 3.2*2.5*0.7mm

Aging : +/-3ppm/year

Green Product : RoHS Compliant /Pb-Free

Contact Now

SJK-7U 8MHz SMD3225 Quartz Crystal Unit High Precision and Stability appication for indusrtial control

Features:

Reliable seam sealed ceramic package.
Wide operating temperature range.
Superior performance and stringent reliability in harsh environment.
Application: MCU, Industrial Control, Factory Automation, IoT, ABS and sensor modules, etc.
Compact size.
RoHS Compliant / Pb Free.

Specifications:

Item	SJK-7U SMD3225 8MHz Quartz Crystal
Nominal Frequency	8MHz
Overtone Order	AT/Fundamental
Frequency Tolerance (@25ºC)	±10ppm
Load Capacitance	12pF
Drive Level	100μW Typical
Operating Temperature	-40°C to +85°C
Storage Temperature	-55°C to +125°C
Frequency Stability Over Operating Temperature Characteristics	±30ppm
Equivalent Series Resistance(ESR)	150Ω max.
Shunt Capacitance	2pF max.
Aging @25°C 1st year (Max)	±3ppm/year
Package Size(L×W×H)(mm)	3.2×2.5×0.7

Dimensions and Soldering Plattern:

SJK-7U 8MHz SMD3225 Quartz Crystal Unit High Precision And Stability Appication For Indusrtial Control
